Synology DiskStation Compact 2-Bay Network Attached Storage - DS225PLUS

Product Details
Synology DS225PLUS DiskStation Compact 2-Bay Network Attached Storage
The Synology DS225PLUS DiskStation compact 2-bay network attached storage (NAS) enclosure combines built-in 2.5GbE networking with up to 40 TB of raw storage using two separately purchased 20 TB drives.1 Sequential transfers exceed 282 MB/s read and 217 MB/s write in Synology testing.2 A quad-core Intel Celeron J4125 processor and 2 GB of DDR4 non-ECC memory power Synology DiskStation Manager (DSM) for private file access, photo organization, backup and IP-camera recording. Designed for homes, home offices, small teams and branch offices, it brings sharing, synchronization and recovery into one compact private hub.
Key Features
Private Cloud Access with File Version History
Move between mobile apps, desktop clients and browser access without moving your files out of your private storage hub. Synology Drive brings file access and sharing to those different interfaces, while version history lets you roll back a file after accidental deletion, an editing mistake or malware. That recovery path is especially useful when the latest copy is not the one you need.
Automatic Photo Backup and Secure Sharing
Keep photos and media in a private collection, with automatic backup helping bring your content together. Synology Photos adds album organization so collections are easier to browse and secure sharing links for passing along the photos you want others to see.
Real-Time Team Collaboration
Work on documents together instead of passing separate copies back and forth. Synology Office supports real-time editing, while MailPlus provides privately hosted email. Synology Chat adds public, private and group messaging, bringing conversations and collaborative work onto the same privately managed platform.
Multi-Site Synchronization and Cloud Integration
One-way or two-way NAS synchronization helps branch offices keep data aligned with a central office. More than 20 cloud connectors also link NAS storage with services such as Dropbox, Google Drive and Microsoft OneDrive, supporting workflows that span local and cloud storage.
Hybrid Share caches cloud data locally, giving distributed storage a local access point rather than relying only on cloud access. This combines the role of a private storage hub with cloud integration for teams working across locations.3
Backup, Immutable Snapshots and Recovery
Active Backup Suite centralizes protection for Windows, Linux and MacOS devices, virtual machines and cloud accounts. Bare-metal recovery provides a path to restoring a complete device, while scheduled NAS backups protect the storage hub itself. Immutable snapshots and offsite replication add recovery options when mistakes or malware threaten important data.
Surveillance Station for Up to 25 Cameras
Turn private storage into a central hub for IP-camera recording with Surveillance Station, supporting up to 25 cameras at 1080p.4 Compatibility with more than 8,700 IP-camera models gives you a broad selection of cameras for physical security. Two default camera licenses are included; additional licenses and cameras are purchased separately.
Centralized Fleet Monitoring and Administration
Manage multiple Synology systems through Central Management System, using group policies, delegated tasks and batch updates to coordinate administration. Active Insight adds cloud-based visibility into performance, backup status and login activity, helping you oversee systems across locations rather than checking each one in isolation.5
2.5GbE Networking and Push-Button USB Copy
A 2.5GbE port and a separate 1GbE port provide wired network connections, while two USB 3.2 Gen 1 ports accommodate USB devices. The front Copy button transfers data from a connected USB device to the internal drives, making it convenient to bring those files into your private storage hub.
The two bays accept compatible 3.5 in SATA HDDs or 2.5 in SATA SSDs, with drives sold separately.6 HDD Hibernation, Scheduled Power On/Off and Wake on LAN give you options for managing when the system and drives are active.
Features
Synology Drive Private Cloud
Reach your files across devices and recover earlier versions after unwanted changes.
Synology Photos
Back up media automatically, organize albums and share photos through secure links.
Private Team Collaboration
Create shared documents, host email and keep team conversations together.
One-Way or Two-Way NAS Synchronization
Keep files in step between home, office and branch locations.
Hybrid Share Local Caching
Access cloud data through a local cache.3
More Than 20 Cloud Connectors
Connect storage workflows with services including AWS S3 and BackBlaze B2.
Centralized Backup and Bare-Metal Recovery
Protect endpoints, virtual machines, cloud accounts and NAS data.
Immutable Snapshots and Offsite Replication
Preserve additional recovery paths for important files.
Up to 25 IP Cameras at 1080p
Consolidate camera recording with Surveillance Station and two included camera licenses.4
Central Management System and Active Insight
Coordinate fleet administration and track performance, backups and login activity.5
Quad-Core Intel Celeron and 2 GB DDR4
The J4125 processor and installed non-ECC memory support DSM storage applications.
2.5GbE and 1GbE Networking
Use the two built-in Ethernet ports for wired network access.
Two USB 3.2 Gen 1 Ports and USB Copy
Import connected USB-device data with the front Copy button.
Two SATA Bays and Up to 40 TB Raw Capacity
Build storage around compatible HDDs or SSDs purchased separately.16
HDD Hibernation and Power Scheduling
Manage active periods with Scheduled Power On/Off and Wake on LAN.
Footnotes
1 The 40 TB raw capacity is calculated using two 20 TB drives, sold separately. Usable capacity depends on the installed drives and RAID configuration; filesystem and system metadata reduce usable space.
2 Transfer figures are from Synology internal testing. Actual performance varies with environment, usage, configuration and concurrent applications.
3 C2 Storage for Hybrid Share requires an eligible monthly or annual subscription.
4 The 25-camera figure is the recommended count at 1080p. Recording capabilities vary with codec, resolution, drives, configuration, features and workload. Surveillance Station includes two default licenses; additional cameras or devices require purchased licenses. Cameras are not included.
5 Active Insight includes three free licenses. Additional licenses require annual subscriptions.
6 Consult the current Synology drive compatibility list before purchasing drives. Guaranteed functionality, reliability and performance apply to compatible drives. Drives are sold separately.
Read More
California customers
Proposition 65 WARNING
WARNING: Cancer and Reproductive Harm

Specifications
General
Color
Matte Black
Type
Network Attached Storage
In the Box
1 x Main Unit, 1 x AC Power Adapter, 1 x AC Power Cord, 2 x RJ-45 LAN Cables, 10 x Screws For 2.5 in Drives
Form Factor
Desktop
Interface
SATA
Compatibility
Synology Compatible SATA Drives; Windows, Linux, MacOS Devices (Active Backup Suite)
Max Operating Temperature
104 degrees F (40 degrees C)
Series
DiskStation
Frequency
50Hz To 60Hz, Single Phase (AC Power Adapter)
Input Devices
No
Line Voltage
100-240V AC (AC Power Adapter)
Media Card Reader
No
Operating Humidity
8% To 80% RH
Operating System
Synology DiskStation Manager (DSM)
Operating System Platform
Synology
Operating Temperature
32 degrees F To 104 degrees F (0 degrees C To 40 degrees C)
Power Supply
60W AC Power Adapter
Storage Temperature
-4 degrees F To 140 degrees F (-20 degrees C To 60 degrees C)
Typical Acoustical Performance
19.6 dBA
Hard Drive/Solid State Drive Information
Capacity
0TB (Drives Not Included)
Sequential Read Speed
Over 282 MB/s (With Installed Drives; Internal Testing)
Sequential Write Speed
Over 217 MB/s (With Installed Drives; Internal Testing)
CPU Performance
Processor Core
4
Processor Thread
4
Processor Manufacturer
Intel
Processor Model
Intel Celeron
Processor Type
J4125
Processor Speed
2.0GHz
Processor Turbo Boost Speed
2.7GHz
Case Information
Case Size
Compact
Case Storage
2 x 3.5 in SATA HDD Or 2.5 in SATA SSD (Drives Sold Separately)
Fan Support
1 x 92mm x 92mm System Fan
Input/Output Ports
2 x USB 3.2 Gen 1, 1 x RJ-45 1GbE LAN, 1 x RJ-45 2.5GbE LAN
Storage
Storage Size
0TB (Drives Not Included)
Optical Drive
No
Recordable DVD Drive
No
Storage Type
Drives Not Included
Cooling Information
Fan Size
92mm x 92mm x 25mm (System Fan)
Power Draw
16.98W Access, 6.08W HDD Hibernation
Sound Level
19.6 dBA
Number Of Fans
1
Memory
Memory Technology
DDR4
System Memory (RAM)
2GB
RAM Expandable To
6GB
Power Supply Information
AC Input Range
100-240Vac (AC Power Adapter)
Total Output
60W (AC Power Adapter)
Display
Display Type
Display Not Included
Monitor
No
Touch Screen
No
Motherboard Information
Supported Memory
6GB Max DDR4 Non-ECC
Supported Operating Systems
Windows, Linux, MacOS (Active Backup Suite)
Supported Storage
2 x 3.5 in SATA HDD Or 2.5 in SATA SSD (Drives Sold Separately)
Ethernet
1 x 1GbE, 1 x 2.5GbE
Back Panel I/O Ports
1 x USB 3.2 Gen 1, 1 x RJ-45 1GbE LAN, 1 x RJ-45 2.5GbE LAN, 1 x Power Port, 1 x Kensington Security Slot
Manageability
Synology DiskStation Manager, Central Management System, Active Insight
Interfaces/Ports
HDMI Output
No
Interfaces/Ports
2 x USB 3.2 Gen 1, 1 x RJ-45 1GbE LAN, 1 x RJ-45 2.5GbE LAN, 1 x Power Port, 1 x Kensington Security Slot
Processor Information
Architecture
64-Bit
Number Of Cores
4
Number Of Threads
4
Max Boost Clock Speed
2.7GHz
Base Clock Speed
2.0GHz
Native Ports
2 x USB 3.2 Gen 1
System Memory
DDR4
Communication
Webcam
No
System Memory (RAM)
Memory Size
2GB
Memory Standard
DDR4
Error Checking
Non-ECC
Device Supported
Network Attached Storage
Keyboard/Touchpad
Keyboard
No
Pointing Device
No
Backlit Keyboard
No
Warranty Information
Parts Warranty
3 Years Limited
Approximate Weight
Package Weight (lbs)
5
Approximate Dimensions
Package Size HxWxL (in)
5 x 11 x 12
